Appendix 25
Appendix
5
Specifications
General
Power requirements Refer to main label.
Power consumption Refer to main label.
Dimensions (W x H x D) (39 x 3 x 20) inches without foot
Net Weight (Approx.) 5.1 lbs
Operating temperature 41 °F to 95 °F (5 °C to 35 °C)
Operating humidity 5 % to 90 %
Bus Power Supply (USB) DC 5 V
0
500 mA
Inputs
DIGITAL IN (OPTICAL IN) 3 V (p-p), Optical jack x 2
PORT. IN 0.5Vrms (3.5 mm stereo jack)
Amplier
Stereo mode 70 W + 70 W (4 Ω at 1 kHz)
Subwoofer 140 W (3 Ω at 60 Hz)
Wireless subwoofer
Power requirements Refer to main label on the Subwoofer.
Power consumption Refer to main label on the Subwoofer.
Reception Output 5.8 GHz
Type 1 Way 1 Speaker
Impedance Rated 3 Ω
Input Power 140 W
Max. Input Power 280 W
Net Dimensions (W x H x D) (8 x 15 x 12) inches
Net Weight 15.2 lbs
Designs and specications are subject to change without prior notice.
