ART COOL Mirror
Display & signal receiver
Part Name
Front panel
Air suction grille
Installation plate
Knockout hole For pipe and cable
5
No.
2
4
3
1
Remark
Note
912(35.9)
354(13.9)
567(22.3)
77(3.0)
148(5.8)
107(4.2)
282(11.1)
282(11.1)
51(2.0)
53(2.1)
37(1.5)
51(2.0)
50(2.0)
5
165(6.5)
2
4
171(6.7)
3
1. Unit should be installed in compliance with the installation manual
in the product box.
2. Unit shall be grounded in accordance with the local regulations or
applicable national codes.
3. The Unit is powered from the outdoor unit. Therefore power cable
should be connected with the outdoor unit.
1
CHASSIS CODE: SE
