LG LSRG309ST Service Manual

(P AGE )
GENERAL -------------------------------------------------------------------------------------------- 1-1 ~ 1-5
• Important safety instructions -------------------------------------------------------------------------------------- 1-1 ~ 1-3
• Model & Serial number label and tech sheet locations ----------------------------------------------------------- 1-4
• Specifications ------------------------------------------------------------------------------------------------------------------ 1-5
USING YOUR RANGE
------------------------------------------------------------------------- 2-1 ~ 2-5
• General imformation --------------------------------------------------------------------------------------------------------- 2-1
• Control panel features ---------------------------------------------------------------------------------------------- 2-2 ~ 2-4
- To turn on on the surface burners
- Setting the Clock
- Start, Clean/Off and On/Off pad
- To turn On/Off the oven light
- Timer On/Off
- Warm(Options: Hold 3 sec) pad: (6 types of category).
- Bake, Timed Bake, Delayed timed Bake
- Broil
- Convection Bake
- Convection Roast
- Favorite
- Warm
- Time cook with warm
- Oven lockout
- Changing hour mode on clock (12HR, 24HR)
- Proof
- Self-Clean
• Warming drawer -------------------------------------------------------------------------------------------------------------- 2-5
COMPONENT ACCESS --------------------------------------------------------------------- 3-1 ~ 3-21
• Component Locations ------------------------------------------------------------------------------------------------------ 3-1
• Removing the Back, Control cover and Key pad assembly ----------------------------------------------------- 3-2
• Removing the Spark Module(IG Trans) and Power Control Board (PCB) --------------------------------- 3-3
• Removing the Cooktop Plate -------------------------------------------------------------------------------------------- 3-4
• Removing the Case assembly(Cooktop Burner assembly) ----------------------------------------------------- 3-5
• Removing the Cooktop Parts -------------------------------------------------------------------------------------- 3-6~3-7
• Removing the Door Latch and the Door Switch --------------------------------------------------------------------- 3-8
• Removing the BROIL Burner assembly ------------------------------------------------------------------------------- 3-9
• Oven Bottom, the Frame guide and the Burner assembly ----------------------------------------------------- 3-10
• Removing the CONVECTION an blade and Fan motor -------------------------------------------------------- 3-11
• Removing the Oven light & Socket assembly ---------------------------------------------------------------------- 3-12
• Removing the latch drive assembly ----------------------------------------------------------------------------------- 3-13
- Door locking mechanism ---------------------------------------------------------------------------------------------- 3-13
• Removing the Oven temperature Sensor --------------------------------------------------------------------------- 3-14
• Removing & Replacing the Warming drawer element ----------------------------------------------------------- 3-15
• Removing & Replacing the Lift-off Oven Door --------------------------------------------------------------------- 3-16
• Removing the Oven Door Handle & Glass ---------------------------------------------------------------- 3-17 ~ 3-18
• Removing the Oven Door Gasket & Drawer Gasket ------------------------------------------------------------- 3-19
• Removing a Side Panel --------------------------------------------------------------------------------------------------- 3-20
• Removing the Oven Valve (Safety Valve) & Gas Regulator --------------------------------------------------- 3-21
