LG LU34 Series - External Speakers; Wired Network Connection

ENGLISH
9
External Speakers
EXTERNAL
SPEAKER OUT
RIGHT
LEFT
GND
GND
• Use only with the 3 Pole 3.5 mm Stereo Jack.
• Do not connect your headphones or earphones to the port
for connecting an external speaker.
Network
Wired network connection
This TV can be connected to a Pro:Centric server via the LAN port. After
making the physical connection, the TV needs to be set up for network
communication.
Connect the LAN port of the Modem or Router from Pro:Centric server
to the LAN port on the TV.
Pro:Centric Server
Broadband Modem
Pro:Centric Server
Router
Broadband Modem
1
Connect the LAN port of the Modem or Router to the LAN port
on the TV.
• Do not connect a modular phone cable to the LAN port.
• Since there are various connection methods, please follow
the specifications of your telecommunication carrier or
internet service provider.
