LG LU34 Series - Supported Photo Formats; Supported Audio Formats

ENGLISH
15
Supported Photo Formats
Extension Item Resolution
.jpeg, .jpg,
.jpe
Available File
Type
SOF0 : Baseline
SOF1 : Extend Sequential
SOF2 : Progressive
Photo Size
Minimum: 64 (W) x 64 (H)
Maximum (Normal Type):
15360 (W) x 8640 (H)
Maximum (Progressive Type):
1920 (W) x 1440 (H)
.bmp Photo Size
Minimum: 64 (W) x 64 (H)
Maximum: 9600 (W) x 6400 (H)
.png
Available File
Type
Interlace, Non-Interlace
Photo Size
Minimum: 64 (W) x 64 (H)
Maximum (Interlace):
1200 (W) x 800 (H)
Maximum (Non-Interlace):
9600 (W) x 6400 (H)
• BMP and PNG format files may be slower to display than JPEG.
• Non-standard photo/image file may not be displayed.
Supported Audio Formats
File
type
Item Info
mp3
Bit rate 32 Kbps - 320 Kbps
Sample freq. 16 kHz - 48 kHz
Support MPEG-1, MPEG-2, Layer2, Layer3
AAC
Bit rate Free Format
Sample freq. 8 kHz - 48 kHz
Support ADIF, ADTS
M4A
Bit rate Free Format
Sample freq. 8 kHz - 48 kHz
Support MPEG-4
WAV
Bit rate 64 kbps ~ 1.5 Mbps
Sample freq. 8 kHz - 48 kHz
Support LPCM
Bitdepth 8 bit / 16 bit / 24 bit
WMA
Bit rate 128 Kbps ~ 320 Kbps
Sample freq. 8 kHz - 48 kHz
Support WMA7, WMA8, WMA9 Standard
WMA 10
Pro
Bit rate ~ 768 Kbps
Channel /
Sample freq.
M0: up to 2 Channel @ 48 kHz
(Except LBR mode),
M1: up to 5.1 Channel @ 48 kHz,
M2: up to 5.1 Channel @ 96 kHz
Support WMA 10 Pro
OGG
Bit rate Free Format
Sample freq. 8 kHz - 48 kHz
Support OGG Vorbis
