57
MAINTENANCE
ENGLISH
Removing and Replacing the Lift-Off
Oven Doors
CAUTION
•
Be careful when removing and lifting the door.
•
Do not lift the door by the handle. The door is
very heavy.
Removing the Door
1
Open the door fully.
2
Pull the hinge locks down toward the door frame
to the unlocked position.
Slot
Lock
Unlock
Hinge
lock
Hinge
arm
Hinge lock open
3
Firmly grasp both sides of the door at the top.
4
Close door to the door removal position, which is
approximately 5 degrees.
about 5°
5
Lift door up and out until the hinge arm is clear
of the slot.
Replacing the Door
1
Firmly grasp both sides of the door at the top.
2
With the door at the same angle as the removal
position, seat the indentation of the hinge arm
into the bottom edge of the hinge slot. The notch
in the hinge arm must be fully seated into the
bottom of the slot.
Hinge arm
Indentation
Bottom
edge of slot
3
Open the door fully. If the door will not open fully,
the indentation is not seated correctly in the
bottom edge of the slot.
4
Push the hinge locks up against the front frame
of the oven cavity to the locked position.
Hinge arm
Hinge lock
Hinge locked
5
Close the oven door.
Door Care Instructions
Most oven doors contain glass that can break.
CAUTION
•
Do not close the oven door until all the oven
racks are fully in place.
•
Do not hit the glass with pots, pans, or any
other object.
•
Scratching, hitting, jarring, or stressing the
glass may weaken its structure causing an
increased risk of breakage at a later time.
