LGE Internal Use OnlyCopyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
- 6 -
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
4. Module Specification
M215HW03-V1
1. Application Range.
This spec sheet is applied to the 56 cm(22 inch) LED LCD TV
used LD11D chassis.
2. Specification
Each part is tested as below without special appointment
2.1 Temperature : 25 °C ± 5 °C (77 °F ± 9 °F),
CST : 40 °C ± 5° C
2.2 Relative Humidity : 65 % ±10 %
2.3 Power Voltage : Standard input voltage
(100 V - 240 V ~, 50 / 60 Hz)
• Standard Voltage of each products is marked by models
2.4 Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM .
2.5 The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
3.1 Performance : LGE TV test method followed.
3.2 Demanded other specification
Safety : CB
No Item Specification Unit Remark
1 Panel Size 546.86mm(22.53 inches)
2 Panel Type TN
3 Operating Mode Normally White
4 Backlight Unit White LED
5 Max Resolution 1920 x 1080
6 Pixel Pitch 0.248(H) x 0.248(V)
7 Interface LVDS 2Port
8 Color depth 16.7M (6bit+A FRC)
4.2. Optical Spec.
No. Item Specification Min. Typ. Max. Remark
1 Viewing Angle[CR>10] Right/Left 75/75 85/85 -
Up/Down 70/70 80/80
2 Luminance Luminance (cd/m2) 200 250 -
Variation(%) 75 %
3 Contrst Ratio CR 600 1000
4 Color Coordinates RED R
x
- 0.641 -
R
y
- 0.333 -
Green G
x
- 0.331 -
G
y
- 0.626 -
Blue B
x
- 0.155 -
B
y
- 0.047 -
White W
x
- 0.313 -
W
y
- 0.329 -
