APPENDIX
Command Reference List
CCOOMMMMAANNDD11 CCOOMMMMAANNDD22
19. Channel Tuning
DATA
(Hexadecimal)
CCOOMMMMAANNDD11 CCOOMMMMAANNDD22
DATA
(Hexadecimal)
CCOOMMMMAANNDD11 CCOOMMMMAANNDD22
DATA00
(Hexadecimal)
DATA01
(Hexadecimal)
DATA02
(Hexadecimal)
DATA03
(Hexadecimal)
DATA04
(Hexadecimal)
DATA05
(Hexadecimal)
physical major major low minor high minor low attribute
program high program low
ma
01. Power k a 00 to 01
02. Input Select x b (
G
p.90)
03. Aspect Ratio k c (
G
p.90)
04. Screen Mute k d 00
to 01
05. Volume Mute k e 00
to 01
06. Volume Control k f 00
to 64
07. Contrast k g 00
to 64
08. Brightness k h 00
to 64
09. Color k i 00
to 64
10. Tint k j 00
to 64
11. Sharpness k k 00
to 64
12. OSD Select k l 00
to 01
13. Remote Control
Lock Mode
Transmission / Receiving Protocol
TTrraannssmmiissssiioonn
[Command 1] : First command to control the set.
(j, k, m or x)
[Command 2] : Second command to control the set.
[Set ID] : You can adjust the set ID to choose desired set ID
number in Option menu. Adjustment range is 1
to 99.
When selecting Set ID ‘0’, every connected the set is
controlled. Set ID is indicated as decimal
(
1
to 99
)
on menu and as Hexa decimal
(
0x0
to 0x63
)
on trans-
mission /receiving protocol.
[DATA] : To transmit the command data.
Transmit the ‘FF’ data to read status of command.
[Cr] : Carriage Return
ASCII code ‘0x0D’
[ ] : ASCII code ‘space (0x20)’
* In this model, set will not send the status during the standby mode.
OOKK AAcckknnoowwlleeddggeemmeenntt
The set transmits ACK (acknowledgement) based on this for-
mat when receiving normal data. At this time, if the data is
data read mode, it indicates present status data. If the data is
data write mode, it returns the data of the PC computer.
* In this model, set will not send the status during the standby mode.
* Data Format
[Command 2] : Use as command.
[Set ID] : Use the small character, if set ID is 10, it will send the ‘0’, ‘a’.
[DATA] : Use the small character, if data is 0 x ab, it will send the ‘a’, ‘b’.
[OK] : Use the large character.
EErrrroorr AAcckknnoowwlleeddggeemmeenntt
The set transmits ACK (acknowledgement) based on this for-
mat when receiving abnormal data from non-viable functions
or communication errors.
Data1: Illegal Code
Data2: Not supported function
Data3: Wait more time
* In this model, set will not send the status during the standby mode.
* Data Format
[Command 2] : Use as command.
[Set ID] : Use the small character, if set ID is 10, it will send the ‘0’, ‘a’.
[DATA] : Use the small character, if data is 0 x ab, it will send the ‘a’, ‘b’.
[NG] : Use the large character
[[CCoommmmaanndd11]][[CCoommmmaanndd22]][[ ]][[SSeett IIDD]][[ ]][[DDaattaa]][[CCrr]]
[[CCoommmmaanndd22]][[ ]][[SSeett IIDD]][[ ]][[OOKK]][[DDaattaa]][[xx]]
[[CCoommmmaanndd22]][[ ]][[SSeett IIDD]][[ ]][[NNGG]][[DDaattaa]][[xx]]
14. Treble k r 00 to 64
15. Bass k s 00
to 64
16. Balance k t 00
to 64
17.
Color Temperature
k u 00
to 02
18. Auto Configuration j u (
G
p.91)
20. Channel Add/Del m b 00
to 01
21 . K e y m c (
G
p.92)
22. Backlight m g 00
to 64
00
to 01
k m
To Next Page
