9. RGB Input ( PC )
No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Remark
1 640*480 31.469 59.94 25.175
2 800*600 37.879 60.317 40.0
3 1024*768 48.363 60.0 65.0
4 1152*864 54.34 60.05 80
5 1280*960 60 60 108.0
6 1280*1024 63.981 60.02 108.0
7 1680*1050 64.674 59.883 119.0
8 1680*1050 65.290 59.954 146.25
9 1920*1080 67.5 60 148.5
10. HDMI Input (DTV)
No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Proposed
1 720*480 15.75 60.00 13.514 SDTV, DVD 480I(525I)
2 720*480 15.73 59.94 13.500 SDTV, DVD 480I(525I)
3 720*576 15.625 50.00 13.500 SDTV, DVD 576I(625I) 50Hz
4 7Z20*480 31.47 59.94 27.000 SDTV 480P
5 720*480 31.50 60.00 27.027 SDTV 480P
6 720*576 31.25 50.00 27.000 SDTV 576P 50Hz
7 1280*720 44.96 59.94 74.176 HDTV 720P
8 1280*720 45.00 60.00 74.250 HDTV 720P
9 1280*720 37.50 50.00 74.25 HDTV 720P 50Hz
10 1920*1080 33.72 59.94 74.176 HDTV 1080I
11 1920*1080 33.75 60.00 74.250 HDTV 1080I
12 1920*1080 28.125 50.00 74.250 HDTV 1080I 50Hz
13 1920*1080 67.432 59.94 148.350 HDTV 1080P
14 1920*1080 67.5 60 148.5 HDTV 1080P
15 1920*1080 56.250 50 148.5 HDTV 1080P 50Hz
