LG M2380A-PMM User Manual

No Item module Min Typ Max Remark
1 20/22/23 inch
4,000,000:1 5,000,000:1 PC Mode(D-sub) For Checking Black Luminance,
wait for over 1 minute.
LGE Internal Use OnlyCopyright LG Electronics. Inc. All right reserved.
Only for training and service purposes
- 10 -
8. Component Video Input (Y, PB, PR)
7. SET Optical Feature
7.1 PC Mode (Measurement Condition: Full white/ Standard/6500k) ? Measure the black luminance after 30 seconds.)
No Item module
Luminance (cd/m
2
) C/R(min)
Remark
Min Typ Max Min Typ
1 20/22/23 inch LGD 200 230 - 500:1 700:1
RGB
DFC 5,000,000:1
No.
Specification
Remark
Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz)
1. 720*480 15.73 59.94 13.500 SDTV, DVD 480I(525I)
2. 720*480 15.75 60.00 13.514 SDTV, DVD 480I(525I)
3. 720*576 15.625 50.00 13.500 SDTV, DVD 576I(625I) 50Hz
4. 720*480 31.47 59.94 27.000 SDTV 480P
5. 720*480 31.50 60.00 27.027 SDTV 480P
6. 720*576 31.25 50.00 27.000 SDTV 576P 50Hz
7. 1280*720 44.96 59.94 74.176 HDTV 720P
8. 1280*720 45.00 60.00 74.250 HDTV 720P
9. 1280*720 37.50 50.00 74.25 HDTV 720P 50Hz
10. 1920*1080 33.72 59.94 74.176 HDTV 1080I
11. 1920*1080 33.75 60.00 74.250 HDTV 1080I
12. 1920*1080 28.125 50.00 74.250 HDTV 1080I 50Hz,
13. 1920*1080 56.25 50 148.5 HDTV 1080P
14. 1920*1080 67.432 59.94 148.350 HDTV 1080P
15. 1920*1080 67.5 60.00 148.5 HDTV 1080P
7.3 Special feature(DFC)
-DFC Working Condition : Full Black Pattern(All Black, No pattern(MSPG Pattern#2)) signal in D-sub
No Item
Luminance(cd/m
2
) C/R(min)
Remark
Typ Max RF,AV,COMPONENT,HDMI
1 20 inch 170 200 500:1 RF, AV, COMPONENT, HDMI
2 22 inch 170 200 500:1
3 23 inch 170 200 500:1
7.2 AV Mode
(Measurement Condition: Full white(100IRE)/ Vivid) ? Measure the black luminance after 30 seconds.

LG M2380A-PMM Specifications

General

Brand	LG
Model	M2380A-PMM
Category	LCD TV
Language	English
