6. Chroma & Brightness
* Optical Test Condition
- Surrounding Brightness Level : dark
- Surrounding Temperature : 25 °C ± 5 °C
- warm-up Time : 30 min
- Contrast, Brightness : Outgoing condition
- *Incase of Vivid Mode, high level saturation may be occurred. Check gray linearity at standard mode.
* Active area
1. Active area of LCD PANEL is in bezel of cabinet.
2. Interval between active area and bezel
|A-B|<1.0 mm , |C-D|<1.0 mm
A: Interval between left of active area and bezel
B: Interval between right of active area and bezel
C: Interval between top of active area and bezel
D: Interval between bottom of active area and bezel
C
B
D
A
Active Area
Bezel
No. Item Specification Min. Typ. Max. Remark
1 Viewing Angle[CR>10] Right/Left 70/70 85/85 - CR >10
Up/Down 60/70 75/85
2 Luminance Luminance (cd/m
2
) 200 250 -
Variation(%) 75 Min/ Max
3 Contrst Ratio CR 700 1000
Full white/Full black
4 Color Coordinates [CIE1931] White W
X
0.313
W
Y
Typ. 0.329 Typ.
RED R
X
-0.03 0.628 +0.03 RGB
R
Y
0.348 Vivid, 6500K
Green G
X
0.345 Full white(100IRE)
G
Y
0.615
Blue B
X
0.153
B
Y
0.057
5 Response Time(ms) Rise Time TrR 1.3 2.6
Condition : DVI or RGB
Decay Time TrD 3.7 7.4
Standard, Backlight100
