LG M2380D - Page 145

145
APPENDIX
M2780D / M2780DF / M2780DN
LCD Panel
Screen Type
685.8 mm Wide (27 inch) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 685.8 mm
Pixel Pitch
0.3114 mm (H) x 0.3114 mm (V)
Video Signal
Max. Resolution
1920 x 1080 @ 60 Hz
Recommended Resolution
1920 x 1080 @ 60 Hz
Horizontal Frequency
30 kHz to 83 kHz
Vertical Frequency
56 Hz to 75 Hz
Synchronization Type
Separate Sync, Digital
Input Connector
TV, D-Sub Analog, SCART, PC Audio In, component, HDMI*2, CVBS
Power
Rated Voltage
19 V 2.8 A
Power Consumption
On Mode 47 W (typ.)
Off Mode ≤ 1 W
AC/DC Adapter Manufacturer: LITE-ON, Model PA-1650-68
Tilt Tilt Range
-5° to 10°
Dimensions (Width x Height x Depth)
Weight
M2780D
644 mm x 480.6 mm x 222.8 mm (23.53 inch x 18.92 inch x 8.77 inch)
5.8 kg ( 12.79 lb)
M2780DF
644 mm x 493.6 mm x 221.7 mm (23.53 inch x 19.43 inch x 8.72 inch)
6.1 kg ( 13.45 lb)
M2780DN
644 mm x 407.8 mm x 57.6 mm ( 23.53 inch x 16.05 inch x 2.27 inch)
4.8 kg ( 10.58 lb)
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
Storage Temperature
Storage Humidity
■ The specifications shown above may be changed without prior notice for quality improvement.
