LG M3201C User Manual

4
Using the Remote Control
• Power On/Off Button
• AV Button
• Input Select Button
(See next page)
• Sleep Button
When watching AV/S-Video/RGB/HDMI
• Component1/ Component2
The product will be automatically turned off
after a certain period of time.
Press this button repetitively to select an
appropriate time duration
• Menu Button
• Exit Button
• Auto Button
Automatic adjustment function
(Operational for the analog signal only)
• Check Button
• Video Operation Button
Applicable for LG products only
• Volume Button
• Mute button
Name of the Remote Control Buttons (A type)
There is not a function
which is supported
• PSM Button
- Automatically adjusts the image.
Press this button repetitively to set
the intended screen.
• UP and Down buttons
Bring up and down direction adjustment.
• ARC button
To select the image
size of the screen.

LG M3201C Specifications

Panel Specifications

LCD Panel Type	32” Widescreen TFT LCD
Display Area	31.5” diagonal
Aspect Ratio	16:9
Native Resolution	1366 x 768
Brightness	500 cd/m2
Contrast Ratio	1600:1
Response Time	8 ms
Viewing Angle	178 / 178

Video Specifications

Max Input Resolution	768p
H-Scanning Frequency	RGB : 30 - 83 kHz; HDMI/DVI : 30 - 72 kHz
V-Scanning Frequency	56 - 85 Hz

Power Specifications

Rated Voltage	AC 100-240V~ 50/60Hz 1.5A
On Mode Power	145W
DPM Off Power	1W
Off Mode Power	1W

Environmental Conditions

Operational Temperature	50°F ~ 95°F, 10°C ~ 35°C
Operational Humidity	10% ~ 80%
Storage Temperature	-4°F ~ 140°F, -20°C ~ 60°C
Storage Humidity	5% ~ 95%

Cabinet Specifications

Monitor Dimensions (W x H x D)	31.62” x 19.41” x 3.94”
Weight (Head Only)	46.52 lbs
Carton Dimensions (W x H x D)	36.11” x 27.72” x 13.07”
Packed Weight	52.91 lbs

Audio Features

Max Audio Output	20Watt (10W x 2EA)
Audio Built-in AMP	Yes
Audio Features	Equalizer, Auto Volume Limiter, Balance, Speaker on/off
