17
• Select Component.
Connect the video/audio cable as shown in the below figure and then, connect the power
cord (See page 10).
• Connect the input terminal with a proper color match.
BNC Cable
(not included)
Product
HDTV Receiver
Select an input signal.
Press the INPUT button on the remote control to select the input signal.
Or, press INPUT on the bottom of the set.
Audio Cable
(not included)
Connecting to External Devices
Note
- Some devices may require HDCP in order to display HD signals.
- Component doesn't support HDCP.
Component Input (480i/480p/576i/576p/720p/1080i/1080p)
INPUT → → OK
1
2
INPUT →◄ ► → AUTO/SET
Input List
AV Component RGB HDMI/DVI SuperSign
To Next Page
