10
First of all, see if the computer, product and the peripherals are turned off. Then, connect
the signal input cable.
When connecting with the D-Sub signal input cable.
When connecting with the HDMI-DVI signal input cable (not included).
* When HDMI PC is used, a compatiblity problem might occur.
MAC
Macintosh Adapter (not included)
Use the standard Macintosh adapter since an incompatible
adapter is available in the market. (Different signaling system)
Rear back of the set.
Connecting to External Devices
Connect the power cord.
PC
PC/MAC
PC
Rear back of the set.
Rear back of the set.
PC
Rear back of the set.
Connect the Audio cable.
(not included)
(not included)
* User must use shielded signal interface cables (D-sub 15 pin cable, HDMI-DVI cable) with
ferrite cores to maintain standard compliance for the product.
When Connecting to your PC
1
2
3
B.
B.
A.
A.
To Next Page
