1-8
SPECIFICATIONS
GENERAL
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 3.8 kg
External dimensions (W x H x D) 202 x 307 x 262 mm
Operating conditions Temperature 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser, wavelength 650 nm
Tuner FM
FM Tuning Range 87.5 ~ 108.0 MHz or 87.50 ~ 108.0 MHz
FM Intermediate Frequency 128 kHz
AM Tuning Range (optional) 522 ~ 1,620 kHz or 520 ~ 1,710 kHz or 520 ~ 1,710 kHz
AM Intermediate Frequency 45 kHz
AMPLIFIER
Output Power 80 W + 80 W
T.H.D 0.5 %
SPEAKERS (RBS154V)
Type 2 Way 2 Speaker
Impedance 4 Ω
Rated Input Power 50 W
Max. Input Power 100 W
Net Dimensions (W x H x D) 165 x 316 x 198 mm
Net Weight 2.8 kg
Designs and specifications are subject to change without notice.
