Heat pump 50Hz/R410A _ 36
3. Distributor type MULTI F DX (3 phase)
Part 2 Product data_Outdoor units
3.11 Electrical characteristics
Notes :
1. Voltage range
Voltage supplied to the unit terminals should be within the mini-
mum and maximum range
2. Maximum allowable voltage unbalance between phase is 2 %
3. MCA / MOP
MCA = (1.25 x RLA) + Load1 + Load2
MOP = (2.25 x RLA) + Load1 + Load2
- Load1 : sum of current for all other motors
- Load2 : any other load rated 1.0A or more
4. Select wire spec. based on the MCA
5. Select proper circuit breaker as given below
MCA < Circuit breaker ≤ MOP
6. Recommended circuit breaker is ELCB (Earth Leakage circuit
breaker)
7. MSC & RLA are measured as the compressor only test condi-
tion.
8. MSC values
9. RLA is measured during each individual compressor test condi-
tion.
Ex) 5.0 : RLA of (inv. comp.)
10. OFM is measured as the outdoor unit test condition
MCA : Minimum Circuit Amperes (A)
MOP : Maximum rating over current protective device
MSC : Maximum Starting Current
RLA : Rated Load Amperes (A)
OFM : Outdoor Fan Motor
kW : Fan Motor rated output (kW)
FLA : Full Load Amperes (A)
Unit Power Compressor OFM
Model Type Hz Voltage Voltage range MCA MOP RLA KW FLA
A7UW42LFA0
[FM41AH U32]
Inverter 50 380-415
MIN.:342
MAX.:456
12.2 20.8 8.6 0.12 x 2 0.73 x 2
A8UW48LFA0
[FM49AH U32]
12.3 21.0 8.7 0.12 x 2 0.73 x 2
A9UW56LFA0
[FM57AH U32]
12.5 21.3 8.8 0.12 x 2 0.73 x 2
