WIRING
Mid-Static Ducted M1 Chassis
Figure 73: Mid-Static Ducted M1 Chassis Wiring Diagram
Optional Connections
Figure 73 shows the control board for the M1 chassis. Connect optional equipment to the control board as required for your system.
