Indoor unit
16 _ Ceiling Cassette 4-way
Indoor Units
6. Capacity Tables
Cooling capacity
Notes:
TC: Total Capacity(kW)
SHC: Sensible Heat Capacity(kW)
1. Capacity tables show the representative value of conditions
which may occur.
2. Refer to Capacity Correction Factorin the outdoor unit PDBfor
the actual performance data of each indoor unitand outdoor unit
combination.
Capacity
Index
Outdoor
air temp.
(DB, °C)
Indoor air temp. (DB/WB, °C)
20 23 26 27 28 30 32
14 16 18 19 20 22 24
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
4.5
5.6
3.6
10 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.3 2.7 4.7 2.6
12 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.3 2.7 4.7 2.6
14 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.3 2.7 4.6 2.6
16 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.3 2.7 4.6 2.5
18 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.3 2.7 4.5 2.5
20 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.3 2.7 4.4 2.5
21 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.3 2.7 4.4 2.5
23 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.3 2.7 4.3 2.5
25 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.3 2.6 4.3 2.4
27 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.2 2.6 4.2 2.4
29 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.1 2.5 4.2 2.4
31 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.1 2.5 4.1 2.3
33 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 4.0 2.5 4.0 2.3
35 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.9 2.6 3.9 2.5 4.0 2.3
37 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.8 2.5 3.8 2.4 3.9 2.2
39 2.4 2.1 2.9 2.3 3.3 2.5 3.6 2.5 3.7 2.5 3.8 2.4 3.9 2.2
10 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.4 3.6 5.9 3.5
12 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.4 3.6 5.8 3.5
14 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.4 3.6 5.8 3.4
16 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.4 3.6 5.7 3.4
18 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.4 3.6 5.6 3.4
20 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.4 3.6 5.5 3.3
21 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.4 3.6 5.5 3.3
23 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.4 3.6 5.4 3.2
25 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.3 3.5 5.3 3.2
27 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.2 3.4 5.3 3.2
29 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.1 3.4 5.2 3.1
31 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 5.1 3.3 5.1 3.0
33 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 4.9 3.3 5.0 3.0
35 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.8 3.4 4.9 3.2 4.9 3.0
37 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.7 3.3 4.8 3.2 4.9 2.9
39 3.0 2.7 3.6 3.0 4.2 3.2 4.5 3.3 4.6 3.2 4.7 3.1 4.8 2.8
10 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.7 4.2 7.3 4.1
12 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.7 4.2 7.3 4.1
14 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.7 4.2 7.2 4.1
16 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.7 4.2 7.1 4.0
18 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.7 4.2 6.9 4.0
20 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.7 4.2 6.9 3.9
21 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.7 4.2 6.9 3.9
23 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.7 4.2 6.7 3.8
25 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.6 4.1 6.6 3.7
27 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.5 4.1 6.5 3.7
29 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.4 4.0 6.5 3.7
31 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.3 3.9 6.4 3.6
33 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.2 3.9 6.2 3.5
35 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 6.0 4.1 6.1 3.8 6.2 3.5
37 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 5.8 3.9 5.9 3.7 6.1 3.4
39 3.8 3.2 4.5 3.5 5.2 3.8 5.6 3.9 5.7 3.8 5.8 3.7 6.0 3.4
