LG MULTI V ARNU36GBGA4 - Heating Capacity

Indoor unit
8 _ Compact Model
Indoor Units
6. Capacity Tables
6.2 Heating Capacity
Heating capacity
Notes:
TC: Total Capacity(kW)
1. Capacity tables show the representative value of conditions which may occur.
2. is shown as reference. When selecting the outdoor units, avoid the out-
door air temperature range shown by
.
3. In accordance with operation limits of outdoor unit, applicable range of capac-
ity tables is different.
4. Refer to Capacity Correction Factorin the outdoor unit PDBfor the actual per-
formance data of each indoor unitand outdoor unit combination.
Capacity
Index
Outdoor air
temp.
DB(°C) WB(°C)
Indoor air temp. (DB, °C)
16 18 20 21 22 24
TC TC TC TC TC TC
kW kW kW kW kW kW
-24.8 0
-21.8 -22.0
-19.8 -20.0
-18.8 -19.0
-16.7 -17.0
-14.7 -15.0
-12.6 -13.0
-10.5 -11.0
-9.5 -10.0
-8.5 -9.1
-7.0 -7.6
-5.0 -5.6
-3.0 -3.7
0.0 -0.7
3.0 2.2
5.0 4.1
7.0 6.0
9.0 7.9
11.0 9.8
13.0 11.8
15.0 13.7
-24.8 -25.0
-21.8 -22.0
-19.8 -20.0
-18.8 -19.0
-16.7 -17.0
-14.7 -15.0
-12.6 -13.0
-10.5 -11.0
-9.5 -10.0
-8.5 -9.1
-7.0 -7.6
-5.0 -5.6
-3.0 -3.7
0.0 -0.7
3.0 2.2
5.0 4.1
7.0 6.0
9.0 7.9
11.0 9.8
13.0 11.8
15.0 13.7
2.8
4.5
1.9 1.9 1.8 1.8 1.8 1.8
2.2 2.2 2.2 2.2 2.2 2.2
2.4 2.4 2.3 2.3 2.3 2.3
2.4 2.4 2.4 2.4 2.4 2.4
2.5 2.5 2.5 2.5 2.5 2.5
2.7 2.7 2.6 2.6 2.6 2.6
2.8 2.8 2.8 2.8 2.7 2.7
2.9 2.9 2.9 2.9 2.9 2.8
3.0 3.0 2.9 2.9 2.9 2.8
3.0 3.0 3.0 3.0 3.0 2.8
3.1 3.1 3.1 3.1 3.0 2.8
3.2 3.2 3.2 3.1 3.0 2.8
3.4 3.3 3.2 3.1 3.0 2.8
3.4 3.3 3.2 3.1 3.0 2.8
3.5 3.4 3.2 3.1 3.0 2.8
3.6 3.4 3.2 3.1 3.0 2.8
3.6 3.4 3.2 3.1 3.0 2.8
3.6 3.4 3.2 3.1 3.0 2.8
3.6 3.4 3.2 3.1 3.0 2.8
3.6 3.4 3.2 3.1 3.0 2.8
3.6 3.4 3.2 3.1 3.0 2.8
2.9 2.9 2.9 2.9 2.9 2.9
3.5 3.5 3.5 3.5 3.5 3.5
3.7 3.7 3.7 3.7 3.7 3.6
3.8 3.7 3.7 3.7 3.7 3.7
3.9 3.9 3.9 3.9 3.9 3.9
4.1 4.1 4.1 4.1 4.1 4.1
4.3 4.3 4.3 4.3 4.3 4.3
4.5 4.5 4.5 4.5 4.5 4.4
4.6 4.6 4.6 4.6 4.6 4.4
4.7 4.7 4.7 4.7 4.7 4.4
4.8 4.8 4.8 4.8 4.7 4.4
5.0 5.0 5.0 4.8 4.7 4.4
5.3 5.1 5.0 4.8 4.7 4.4
5.3 5.2 5.0 4.8 4.7 4.4
5.5 5.3 5.0 4.8 4.7 4.4
5.6 5.3 5.0 4.8 4.7 4.4
5.6 5.3 5.0 4.8 4.7 4.4
5.6 5.3 5.0 4.8 4.7 4.4
5.6 5.3 5.0 4.8 4.7 4.4
5.6 5.3 5.0 4.8 4.7 4.4
5.6 5.3 5.0 4.8 4.7 4.4
