12 Outdoor Unit
Unit
System(HP)
Model
Product Charge kg
Max. Connectable No. of Indoor Units
Net Weight kg
lbs
Dimensions (WxHxD) mm
inch
Connecting Pipes Liquid [mm(inch)]
Low Pressure Gas [mm(inch)]
High Pressure Gas [mm(inch)]
2 Outdoor Unit
30 32 34 36
ARUB300DT3 ARUB320DT3 ARUB340DT3 ARUB360DT3
ARUB160DT3 ARUB160DT3 ARUB180DT3 ARUB200DT3
ARUB140DT3 ARUB160DT3 ARUB160DT3 ARUB160DT3
14.0 14.0 14.5 16.0
49(60) 52(64) 55(64) 58(64)
270 × 2 270 × 2 270 × 1 + 320 × 1 270 × 1 + 330 × 1
595 × 2 595 × 2 595 × 1 + 705 × 1 595 × 1 + 727 × 1
(1,240 x 1,680 x 760) x 2 (1,240 x 1,680 x 760) x 2 (1,240 x 1,680 x 760) x 2 (1,240 x 1,680 x 760) x 2
(48.8 x 66.1 x 29.9) x 2 (48.8 x 66.1 x 29.9) x 2 (48.8 x 66.1 x 29.9) x 2 (48.8 x 66.1 x 29.9) x 2
19.05(3/4) 19.05(3/4) 19.05(3/4) 19.05(3/4)
34.9(1-3/8) 34.9(1-3/8) 34.9(1-3/8) 41.3(1-5/8)
28.58(1-1/8) 28.58(1-1/8) 28.58(1-1/8) 28.58(1-1/8)
Outdoor units Information
Unit
System(HP)
Model
Product Charge kg
Max. Connectable No. of Indoor Units
Net Weight kg
lbs
Dimensions (WxHxD)
mm
inch
Connecting Pipes Liquid [mm(inch)]
Low Pressure Gas [mm(inch)]
High Pressure Gas [mm(inch)]
2 Outdoor Unit
22 24 26 28
ARUB220DT3 ARUB240DT3 ARUB260DT3 ARUB280DT3
ARUB120DT3 ARUB120DT3 ARUB140DT3 ARUB160DT3
ARUB100DT3 ARUB120DT3 ARUB120DT3 ARUB120DT3
12.8 12.8 13.4 13.4
35(44) 39(48) 42(52) 45(56)
240 × 2 240 × 2 240 × 1 + 270 × 1 240 × 1 + 270 × 1
529 × 2 529 × 2 529 × 1 + 595 × 1 529 × 1 + 595 × 1
(920 x 1,680 x 760) x 2 (920 x 1,680 x 760) x 2
(920 x 1,680 x 760) x 1 (920 × 1,680 × 760) × 1)
(1,240 x 1,680 x 760) x 1 (1,240 × 1,680 × 760) × 1
(36.2 x 66.1 x 29.9) x 2 (36.2 x 66.1 x 29.9) x 2
(36.2 x 66.1 x 29.9) x 1 (36.2 × 66.1 × 29.9) × 1
(48.8 x 66.1 x 29.9) x 1 (48.8 × 66.1 × 29.9) × 1
15.88(5/8) 15.88(5/8) 19.05(3/4) 19.05(3/4)
34.9(1-3/8) 34.9(1-3/8) 34.9(1-3/8) 34.9(1-3/8)
28.58(1-1/8) 28.58(1-1/8) 28.58(1-1/8) 28.58(1-1/8)
n Heat Recovery
Power Supply: Outdoor Unit (3Ø, 460V, 60Hz)
Unit
System(HP)
Model
Product Charge kg
Max. Connectable No. of Indoor Units
Net Weight kg
lbs
Dimensions (WxHxD) mm
inch
Connecting Pipes Liquid [mm(inch)]
Low Pressure Gas [mm(inch)]
High Pressure Gas [mm(inch)]
1 Outdoor unit
8 10 12
ARUB80DT3 ARUB100DT3 ARUB120DT3
ARUB80DT3 ARUB100DT3 ARUB120DT3
5.0 6.4 6.4
13(20) 16(25) 20(30)
190 x 1 240 x 1 240 x 1
418 x 1 529 x 1 529 x 1
(920 x 1,680 x 760) x 1 (920 x 1,680 x 760) x 1 (920 x 1,680 x 760) x 1
(36.2 x 66.1 x 29.9) x 1 (36.2 x 66.1 x 29.9) x 1 (36.2 x 66.1 x 29.9) x 1
9.52(3/8) 9.52(3/8) 12.7(1/2)
19.05(3/4) 22.2(7/8) 28.58(1-1/8)
15.88(5/8) 19.05(3/4) 19.05(3/4)
Unit
System(HP)
Model
Product Charge kg
Max. Connectable No. of Indoor Units
Net Weight kg
lbs
Dimensions (WxHxD) mm
inch
Connecting Pipes Liquid [mm(inch)]
Low Pressure Gas [mm(inch)]
High Pressure Gas [mm(inch)]
1 Outdoor Unit
14 16 18 20
ARUB140DT3 ARUB160DT3 ARUB180DT3 ARUB200DT3
ARUB140DT3 ARUB160DT3 ARUB180DT3 ARUB200DT3
7.0 7.0 7.5 9.0
23(35) 26(40) 29(45) 32(44)
270 x 1 270 x 1 320 × 1 330 × 1
595 x 1 595 x 1 705 x 1 727 x 1
(1,240 x 1,680 x 760) x 1 (1,240 x 1,680 x 760) x 1 (1,240 x 1,680 x 760) x 1 (1,240 x 1,680 x 760) x 1
(48.8 x 66.1 x 29.9) x 1 (48.8 x 66.1 x 29.9) x 1 (48.8 x 66.1 x 29.9) x 1 (36.2 x 66.1 x 29.9) x 1
12.7(1/2) 12.7(1/2) 15.88(5/8) 15.88(5/8)
28.58(1-1/8) 28.58(1-1/8) 28.58(1-1/8) 28.58(1-1/8)
22.2(7/8) 22.2(7/8) 22.2(7/8) 22.2(7/8)
