ENGLISH
Installation Manual 47
Electrical Wiring
n Example Connection of Communication Cable
[BUS type]
•
Connection of communication cable must be installed like below figure between indoor unit to outdoor unit.
[STAR type]
• Abnormal operation can be caused by communication defect, when connection of communication
cable is installed like below figure(STAR type).
