Outdoor Units Information
ENGLISH
Installation Manual 9
Outdoor Units Information
CAUTION
Ratio of the connectable Indoor Units to the Outdoor: Within 50 ~ 130%
Ratio of running Indoor Units to the Outdoor: Within 10 ~ 100%
A combination operation over 100% cause to reduce each indoor unit capacity.
Power Supply: Outdoor Unit (1Ø, 208/230V, 60Hz)
Connectable Indoor Unit
should be connected with "2 series" indoor unit only.
Ex) ARNU073TRC2
System(HP)
Model
Refrigerant Product charge kg(lbs)
Max. Connectable No. of Indoor Units
Net Weight kg(lbs)
Dimensions mm
(WxHxD) inch
Connecting Pipes
Liquid Pipes[mm(inch)]
Gas Pipes[mm(inch)]
45 6
ARUN036GS2 ARUN047GS2 ARUN053GS2
3.0(6.61) 3.0(6.61) 3.0(6.61)
68 9
106(233.7) 106(233.7) 106(233.7)
950×1,380×330 950×1,380×330 950×1,380×330
37.4×54.3×13 37.4×54.3×13 37.4×54.3×13
9.52(3/8) 9.52(3/8) 9.52(3/8)
15.88(5/8) 15.88(5/8) 19.05(3/4)
