LG Multi V PRHR022A - Page 28

28
ENGLISH
[Unit:mm(inch)]
Header
Models Pipe
4 branch
ARBL054
Gas pipe
120(4-23/32)
150(5-29/32)
360(14-3/16)
120(4-23/32)
ID 15.88(5/8)
ID 12.7(1/2)
ID 15.88(5/8)
ID 19.05(3/4)
ID 12.7(1/2)
ID 15.88(5/8)
Liquid pipe
120(4-23/32)
120(4-23/32)
150(5-29/32)
360(14-3/16)
ID 9.52(3/8)
ID 6.35(1/4)
ID 9.52(3/8)
ID 12.7(1/2)
ID 9.52(3/8)
ID 6.35(1/4)
7 branch
ARBL057
Gas pipe
540(21-1/4)
120(4-23/32)
150(5-29/32)
120(4-23/32)
ID 12.7(1/2)
ID 15.88(5/8)
ID 12.7(1/2)
ID 15.88(5/8)
ID 19.05(3/4)
ID 15.88(5/8)
Liquid pipe
540(21-1/4)
120(4-23/32)
150(5-29/32)
120(4-23/32)
ID 6.35(1/4)
ID 9.52(3/8)
ID 9.52(3/8)
ID 12.7(1/2)
4 branch
ARBL104
Gas pipe
120(4-23/32)
150(5-29/32)
400(15-3/4)
160
ID 19.05(3/4)
ID 15.88(5/8)
ID 22.2(7/8)
ID 28.58(1-1/8) ID 25.4(1)
ID 15.88(5/8)
ID 12.7(1/2)
Liquid pipe
120(4-23/32)
120(4-23/32)
150(5-29/32)
360(14-3/16)
ID 9.52(3/8)
ID 6.35(1/4)
ID 9.52(3/8)ID 12.7(1/2)
ID 9.52(3/8)
ID 6.35(1/4)
7 branch
ARBL107
Gas pipe
120(4-23/32)
150(5-29/32)
160
580(22-27/32)
ID 19.05(3/4)
ID 15.88(5/8)
ID 15.88(5/8)
ID 12.7(1/2)
ID 22.2(7/8)ID 28.58(1-1/8) ID 25.4(1)
Liquid pipe
120(4-23/32)
150(5-29/32)
700(27-9/16)
120(4-23/32)
ID 6.35(1/4)
ID 9.52(3/8)
ID 9.52(3/8)
ID 6.35(1/4)
ID 9.52(3/8)ID 12.7(1/2)
Models Pipe
10 branch
ARBL1010
Gas pipe
120(4-23/32)
150(5-29/32)
160
760(29-29/32)
ID 19.05(3/4)
ID 15.88(5/8)
ID 15.88(5/8)
ID 12.7(1/2)
ID 22.2(7/8)ID 28.58(1-1/8) ID 25.4(1)
Liquid pipe
120(4-23/32)
150(5-29/32)
720(28-11/32)
ID 6.35(1/4)
ID 9.52(3/8)
ID 9.52(3/8)
ID 6.35(1/4)
ID 12.7(1/2)
ID 9.52(3/8)
120(4-23/32)
10 branch
ARBL2010
Gas pipe
ID 28.58(1-1/8)ID 31.8(1-1/4) ID 34.9(1-3/8)
120(4-23/32)
150(5-29/32)
182
775(30-1/2)
ID 19.05(3/4)
ID 15.88(5/8)
ID 15.88(5/8)
ID 12.7(1/2)
Liquid pipe
120(4-23/32)
150(5-29/32)
107
60*9=540(21-1/4)
700(27-9/16)
ID 6.35(1/4)
ID 9.52(3/8) ID 19.05(3/4)ID 15.88(5/8)
ID 9.52(3/8)
ID 6.35(1/4)
