Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Figure 105: Remote Control.
Remote
Sensor
Display
Error
Message
Master
Master
AC Smart
ACP Bacnet/ACP LON
(Optional)
Other Building
Mgmt System
(Optional)
LGMV
LGAP Network System
GNDSignal12V
Dry
Contact
(Optional)
Remote Control
Figure below shows an example of a remote control configuration.
CONTROLS SETUP
• Indoor Unit appearances may vary according to model.
