18 | WSU PRODUCT DATA
MULTI V Water 5 Water Source Unit Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
Table 6: Dual Frame 460V Units
GENERAL DATA
Combination Unit Model Number
16.0 Ton
ARWM191DAS5
18.0 Ton
ARWM216DAS5
20.0 Ton
ARWM240DAS5
Individual Component Model Numbers ARWM096DAS5 x 2
ARWM096DAS5 x 1
+ ARWM121DAS5 x 1
ARWM121DAS5 x 2
Cooling Performance
Nominal Cooling Capacity (Btu/h)
1
192,000 216,000 239,400
Heating Performance
Nominal Heating Capacity (Btu/h)
1
216,000 243,000 269,000
Operating Range (Entering Water Temperature)
2
Cooling (°F)
50 - 113 50 - 113 50 - 113
Heating (°F)
50 - 113 50 - 113 50 - 113
Synchronous Operation (°F)
50 - 113 50 - 113 50 - 113
Compressor
Inverter Quantity
HSS DC Scroll x 2
Oil / Type
PVE / FVC68D
Unit Data
Refrigerant Type
R410A
R410A Refrigerant Factory Charge (lbs)
7.7 + 7.7 7.7 + 7.7 7.7 + 7.7
Refrigerant Control / Location
EEV / Indoor Unit
Max. Number Indoor Units / System
32 35 39
Sound Pressure dB(A)
3
53 (65) 57 (65) 59 (65)
Net Unit Weight (lbs.)
328 + 328 328+ 328 328 + 328
Shipping Weight (lbs.)
346 + 346 346 + 346 346 + 346
Communication Cables
5,6
2 x 18 AWG
Heat Exchanger (Stainless Steel Plate)
Maximum Pressure Resistance (psi)
640 640 640
Flow at Rated Condition (GPM)
25.4 + 25.4 25.4 + 30.4 30.4 + 30.4
Total Heat of Rejection (Btu/h)
253,500 283,800 315,800
Total Heat of Absorption (Btu/h)
193,600 221,300 245,400
Pressure Drop (ft-wg)
5.20 / 5.20 5.20 / 7.23 7.23 / 7.23
Δt
4
(°F)
10.0 10.2 10.4
Piping
7
Liquid Line (in.,OD)
3/8 + 3/8 Braze 3/8 + 1/2 Braze 1/2 + 1/2 Braze
High Pressure Vapor Line (in.,OD)
3/4 + 3/4 Braze 3/4 + 3/4 Braze 7/8 + 7/8 Braze
Low Pressure Vapor Line (Heat Recovery only; in.,OD)
7/8 + 7/8 Braze 7/8 + 1-1/8 Braze 1-1/8 + 1-1/8 Braze
Water Inlet / Outlet Connection (in.,ID)
1-1/2 + 1-1/2 FPT 1-1/2 + 1-1/2 FPT 1-1/2 + 1-1/2 FPT
Condensate Pipe Diameter (in.,ID)
3/4 + 3/4 MPT 3/4 + 3/4 MPT 3/4 + 3/4 MPT
Dual Frame 460V Water Source Unit Specications
1
Rated capacity is certified under AHRI Standard 1230. Ratings are subject to change
without notice. Current certified ratings are available at www.ahridirectory.org.
2
Variable water flow control kit PWFCKN000 is required for applications with entering
water temperatures below 590F (one kit per frame). Minimum flow rate must be 40% of the
nominal flow rate, 2-10V signal with a linear flow response valve.
3
Sound pressure levels are tested in an anechoic chamber under ISO 3745 standard
at rated AHRI operating conditions. Sound pressure level may increase during heating
operation at maximum compressor frequency. Value in parenthesis is the maximum sound
pressure at those conditions.
4
Value is calculated as follows: Δt = Total Heat of Rejection ÷ (Rated Flow Rate x 500).
Data is for pure water.
5
Communication cable between WSU, IDU(s) / HRU(s), and Central Controller must be a
minimum of 2-conductor, 18 AWG, twisted, stranded, and shielded. Ensure the
communication cable shield is properly grounded to the WSU chassis only. Do not
ground the communication cable at any other point. Wiring must comply with all applicable
local and national codes.
6
Power wiring is field provided, solid or stranded, and must comply with the applicable
local and national codes.
7
LG requires that LATS software be used on all projects to ensure correct line sizing.
Designer must verify the shop drawing design against the as built design using LATS.
Contractor must also use LG manufactured Y-Branch and Header Kits only.
