MULTI V Water 5 Water Source Unit Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
ELECTRICAL DATA
Table 10: 208-230V, 60Hz, 3-Phase Systems
For component model numbers, see the specification tables.
For 208−230V systems, acceptable voltage range is 187−253V.
Maximum allowable voltage imbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOCP) is calculated as follows: (Largest motor RLA x 2.25) + (Sum of
other motor RLA) rounded down to the nearest standard fuse size.
SCCR rating: 56 kA RMS symmetrical 208V maximum / 62 kA RMS symmetrical 230V maximum
Electrical data for 208–230V Models
Nom.
Tons
System Model No.
Compressor MCA MOCP
Comp.
Qty.
Motor RLA
Frame 1 Frame 2 Frame 3 Frame 1 Frame 2 Frame 3
Frame 1 Frame 2 Frame 3
6 ARWM072BAS5 1 11.1 - - 13.8 - - 20 - -
8 ARWM096BAS5 1 15.5 - - 19.4 - - 30 - -
10 ARWM121BAS5 1 22.2 - - 27.7 - - 45 - -
12 ARWM144BAS5 1 26.2 - - 32.7 - - 50 - -
14 ARWM168BAS5 2 15.5 11.1 - 19.4 13.8 - 30 20 -
16 ARWM192BAS5 2 15.5 15.5 - 19.4 19.4 - 30 30 -
18 ARWM216BAS5 2 22.2 15.5 - 27.7 19.4 - 45 30 -
20 ARWM240BAS5 2 22.2 22.2 - 27.7 27.7 - 45 45 -
22 ARWM264BAS5 2 26.2 22.2 - 32.7 27.7 - 50 45 -
24 ARWM288BAS5 2 26.2 26.2 - 32.7 32.7 - 50 50 -
30 ARWM360BAS5 3 22.2 22.2 22.2 27.7 27.7 27.7 45 45 45
36 ARWM432BAS5 3 26.2 26.2 26.2 32.7 32.7 32.7 50 50 50
