WSU PRODUCT DATA | 23
Water Source Unit Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
Table 11: 460V, 60Hz, 3-Phase Systems
For component model numbers, see the specification tables.
For 460V systems, acceptable voltage range is 414−528V.
Maximum allowable voltage imbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOCP) is calculated as follows: (Largest motor RLA x 2.25) + (Sum of
other motor RLA) rounded down to the nearest standard fuse size.
SCCR rating: 65 kA RMS symmetrical 460V maximum
ELECTRICAL DATA
Nom.
Tons
System Model No.
Compressor MCA MOCP
Comp.
Qty.
Motor RLA
Frame 1 Frame 2 Frame 3 Frame 1 Frame 2 Frame 3
Frame 1 Frame 2 Frame 3
6 ARWM072DAS5 1 7.8 - - 9.8 - - 15 - -
8 ARWM096DAS5 1 8.8 - - 11.1 - - 15 - -
10 ARWM121DAS5 1 11.1 - - 13.8 - - 20 - -
12 ARWM144DAS5 1 13.3 - - 16.6 - - 25 - -
14 ARWM168DAS5 1 15.5 - - 19.4 - - 30 - -
16 ARWM192DAS5 1 20.0 - - 24.9 - - 40 - -
16 ARWM191DAS5 2 8.8 8.8 - 11.1 11.1 - 15 15 -
18 ARWM216DAS5 2 11.1 8.8 - 13.8 11.1 - 20 15 -
20 ARWM240DAS5 2 11.1 11.1 - 13.8 13.8 - 20 20 -
22 ARWM264DAS5 2 13.3 11.1 - 16.6 13.8 - 25 20 -
24 ARWM288DAS5 2 13.3 13.3 - 16.6 16.6 - 25 25 -
30 ARWM360DAS5 2 20.0 15.5 - 24.9 19.4 - 40 30 -
36 ARWM432DAS5 3 13.3 13.3 13.3 16.6 16.6 16.6 25 25 25
42 ARWM504DAS5 3 20.0 15.5 13.3 24.9 19.4 16.6 40 30 25
48 ARWM576DAS5 3 20.0 20.0 20.0 24.9 24.9 24.9 40 40 40
Electrical data for 460V Models
