13
Specifications
Broadcasting Specifications
Digital TV Analogue TV
Television system ISDB-T NTSC-M
Program coverage UHF VHF, UHF, CATV
Maximum number of storable
programs
ISDB-T & Analogue TV : 3000
External antenna impedance 75 Ω
(Only NANO80*)
Wireless module(LGSBWAC02)Specifications
Wireless LAN (IEEE 802.11a/b/g/n/ac)
Frequency range Output power (Max.)
2400 to 2483.5 MHz
5150 to 5725 MHz
5725 to 5850 MHz
18.5 dBm
17 dBm
18.5 dBm
Bluetooth
Frequency range Output power (Max.)
2400 to 2483.5 MHz 8.5 dBm
As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional
frequency table.
For consideration of the user, this device should be installed and operated with a minimum distance of 20 cm between the device and the body.
FCC ID: BEJLGSBWAC02
IC: 2703H-LGSBWAC02
