Getting Started 9
Getting Started
1
4. Attach the bracket cover on the sound bar
with the screws ( 3.0 mm x 8 mm, Tighten the
screws less than 4 torque.).
Bracket cover (Left)
Bracket cover (Right)
5. Attach the bracket (R1 UP/R2 DOWN/L1 UP/L2
DOWN) on the sound bar with the screws
(
3.0 mm x 14 mm).
L2 DOWN bracket
L1 UP bracket
R2 DOWN bracket
R1 UP bracket
