LG OL75DK - General Specifications

Appendix 61
Appendix
6
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption
Refer to the main label on the unit.
Networked standby : 0,5 W
(If all network ports are activated.)
Dimensions (W x H x D) Approx. 330.0 mm x 716.0 mm x 318.0 mm
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 60 % RH
Inputs
Analog audio in (AUX IN 2) 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
Portable in (AUX IN 1) 1.0 Vrms (3.5 mm stereo jack) x 1
Microphone (MIC 1/2) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 2
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 220 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 80 dB
Bus Power Supply (USB)
5 V 0 500 mA
Amplier (RMS Output power)
Total output 600 W RMS
Front 193 W RMS × 2 (4 Ω at 1kHz, 30% THD)
Sub Woofer 214 W RMS (4 Ω at 200Hz, 30% THD)
y Design and specications are subject to change without notice.
