INSTALLATION INSTRUCTIONS
WINDOW VENT PANEL AND EXTENSIONS
The window installation kit allows you to install the air conditioner in most vertical-sliding windows
18" to 50" wide, or casement-style windows from 18" to 50" high.
For an 18" window opening, use the window
vent panel by itself.
For window openings from 19" to 26",
use the window vent panel (Panel A) and a
extension panel (Panel B).
use the window vent panel (Panel A) and a
extension panel (Panel C).
For window openings from 35 " to 50", use the
window vent panel and two extension panels
(Panel C and Panel D).
Panel A
Panel A
18"
18"
Panel A
19"− 26"
19"− 26"
Panel B
Panel A
English
Fig. “a”
Fig. “b”
27"−34"
Fig. “c”
Fig. “d”
For window openings from 27 " to 34",
A B C D
18" 9" 17" 17"
18"
√
a
19"− 26"
√√
b
√√
c
√
d
Fig.
Panel
Window Length
17
√ √
1. Please check your window length and choose the
fit panels from the above tabel.
r e t f a , s l enap 2 nah t e r om deen h t gne l wodn iw r uoy f I . 2
adjust the length, please use type A screw to fix them.
Panel D
Panel A
Panel C
Panel A
Panel C
Panel D
Panel A
Panel C
Screw A
27"− 34"
35"− 50"
27"−34"
35"−50"
35"−50"
Window Installation Kit (includes 1 Window
Vent Panel and 3 Extension Panels)
Panel A (18’’)
Panel C (17’’)
Panel D (17’’)
Panel B (9’’)
1 Window Vent Panel
3 Extension Panels
Panel B
Panel A
Panel C
To Next Page
