13
PREPARATION
Parts and Components
* The projector is manufactured using high-precision technology. You may, however,
see tiny black dots and/or bright colored dots (red, blue or green) that continuously
appear on the projector screen. This is a normal result of the manufacturing process
and does not indicate a malfunction.
$9,1
'&,1
5*%,1
M
ㅁ
VOL -
VOL +
Speaker
Focus ring
Lens
2
Button Description
$9,1
'&,1
5*%,1
M
ㅁ
VOL -
VOL +
(Power)
Turns the projector on or off.
(Menu)
Selects or closes menus.
VOL -, + Adjusts the volume level.
∧, ∨, ＜, ＞
Sets the function or moves the cursor.
(OK) Checks present mode and saves function changes.
1 Due to the high temperature air coming out of the vents, do not get close to the
vents.
2 Do not touch the lens when using the projector or opening the lens cap. The lens
may be damaged.
Control Panel
Back
$9,1
'&,1
5*%,1
M
ㅁ
VOL -
VOL +
To Next Page
