LG PDRYCB300 - Safety Precautions

Safety Precautions
2 Dry contact for thermostat Installation manual 3
ENGLISH
Dry contact for thermostat Owner’s & installation manual
TABLE OF CONTENTS
n Safety Precautions
.............................................................
3~5
n Name of each part
..................................................................
6
n Installation Method
.............................................................
7~8
Installation.................................................................................................8
n Setting and using method
................................................
9~20
1. Power supply and indoor unit connection ...........................................9
2. Setting of Contact Signal Input ..........................................................10
3. Setting of ‘SETTING_SW’..................................................................11
4. Setting of ‘TEMP_SW’ .......................................................................14
5. Installation of thermostat....................................................................15
6. Indoor unit monitoring ........................................................................20
7. Function table for the input signal (For AWHP Indoor unit)...............21
Safety Precautions
To prevent injury to the user or other people and property damage, the following instructions
must be followed.
n Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is
classified by the following indications.
n Meanings of symbols used in this manual are as shown below.
WARNING
CAUTION
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage.
Be sure not to do.
Be sure to follow the instruction.
WARNING
n Installation
Service
Center
Service
Center
Don’t touch with the hands
while the power is on.
• Cause fire, electric shock,
explosion or injury.
Product installation must
be referred to a service
center or installation shop.
• Cause fire, electric shock,
explosion or injury.
Request installation from
installation shop or service
center when reinstalling
the product.
• Cause fire, electric shock,
explosion or injury.
