LG PRDCA0 - Page 22

22
COMMUNICATION KIT INSTALLATION
ENGLISH
• Dip S/W(SW03) NO 4 : ON
Example) 5.85~6.15 Voltage is recognized as 6.0V.
Analog Input 10-4 (VDC)
Room Temp.(°C)
Cooling
Room Temp.(°C)
Heating
Normal
Range
Min. Max.
0.5 0 1.15 Not available Not available
1.5 1.35 1.65 18 16
2 1.85 2.15 18 17
2.5 2.35 2.65 18 18
3 2.85 3.15 19 19
3.5 3.35 3.65 20 20
4 3.85 4.15 21 21
4.5 4.35 4.65 22 22
5 4.85 5.15 23 23
5.5 5.35 5.65 24 24
6 5.85 6.15 25 25
6.5 6.35 6.65 26 26
7 6.85 7.15 27 27
7.5 7.35 7.65 28 28
8 7.85 8.15 29 29
8.5 8.35 8.65 30 30
9.5 8.85 10 Not available Not available
CAUTION
If you want to control the Room Temperature using Remote controller, you have to be off
the Dip S/W 4 and Dip S/W 6, and setting the Rotary S/W to the ‘0’ .
!
