LG RF/RT-20/21CA80VE/VQ/VW User Manual

112 2055-00744L 2055-V1221Y 6341V21006B CPT ASSY
2055-00744L - 6341V21006C CPT ASSY *HAFIDH ,LGEMC,BROTHERS
- 2055-V1221D 6341V21006D CPT ASSY *LGEGF
- 2055-01221C 2426GDA80CC CPT ASSY *TELESTAR
- 2426GCA40CP 2426GDA80AB CPT ASSY *N.ALLIED
2055-00744P 2055-01221C 2055-00691L CPT ASSY *MEEI ,ESSALEM
2055-00744N 2426GCA40CP 2426GDA80CS CPT ASSY *LGEIN
- 2055-01221H - CPT *KIOTA-KI
2055-00746Y - 2055-00691Y CPT ASSY *LGEAL
120 6400VA0001A 120-D38E 120-D38E SPEAKER,MID-RANGE 8 OHM 15/25W
121 - 6400VG0002A 6400VG0002A SPEAKER,TWEETER 8 OHM 10
150 150-D02B 150-D02Y 150-D02X COIL,DEGAUSSING
153 153-113V 6150Z-1014A 6150Z-1023A DY
170 170-A01E 170-A01D 170-A01D LEAD SET,CPT EARTH
174 6410VEH004A 174-225C 174-225C CORD ASSY,POWER
174-009E 174-009E 174-009E CORD ASSY,POWER(W/HOLD,HOUSING)
300 3091V00A83B 3091V00389A 3091V00385A CABINET ASSEMBLY
3091V00A83D 3091V00389D 3091V00385E CABINET ASSEMBLY STEREO
- 3091V00389B 3091V00385B CABINET ASSEMBLY N.ALLIED
3091V00A83C - 3091V00385B CABINET ASSEMBLY GS
310 5020V00650A 5020V00607A 5020V00598A BUTTON
320 320-062H 320-062H 320-062H SPRING,COIL
330 5020V00649A 5020V00609A 5020V00599A BUTTON
340 - 5020V00608A 5020V00600A BUTTON,TURBO
350 - 3750V00021A 3750V00021A RACK BASE ASSY
354 - 4980V00035A 4980V00035A SUPPORTER,BASE NON SWIVEL
400 3809V00A42B 3809V00285A 3809V00285A BACK COVER ASSY
- 3809V00285D 3809V00285D BACK COVER ASSY (JACK)
3809V00A42D - 3809V00285B BACK COVER ASSY(SCART) ESSALEM
- 3809V00285C 3809V00285C BACK COVER ASSY(SCART)
520 6871VMM754T 6871VMM855R 6871VMM855S PWB ASSY,MAIN
- - 6871VMM855U PWB ASSY,MAIN *HAFIDH
6871VMMN52E - 6871VMM792J PWB ASSY,MAIN SCART *LGEMC
- 6871VMM887A 6871VMM887B PWB ASSY,MAIN *LGEGF
- 6871VMM887D 6871VMM887E PWB ASSY,MAIN *MEEI
- 6871VMM887N 6871VMM887P PWB ASSY,MAIN *N.ALLIED
6871VMM815E - 6871VMM887J PWB ASSY,MAIN *ESSALEM
- 6871VMM815D - PWB ASSY,MAIN *KIOTA-KI
- 6871VMMB18D 6871VMMB18E PWB ASSY,MAIN *TELESTAR
6871VMMN52A 6871VMMN52B 6871VMMN52C PWB ASSY,MAIN *LGEIN
6871VMM754V - 6871VMM792M PWB ASSY,MAIN *LGEAL
6871VMM754U - - PWB ASSY,MAIN
540 - 6871VSM360B 6871VSM360B PWB ASSY,TURBO(019A) PIC/SOUND
- 6871VSM360P 6871VSM360P PWB ASSY,TURBO(019A) PIC/SOUND PAKISTAN
550 - 6871VSMD60A 6871VSMD60A PWB ASSY, GAME PAKISTAN
700 - 0IGL120104A 0IGL120104A IC,CDS SENSOR MODULE(P1201-04)
913 332-057A 332-057B 332-057B SCREW ASSY,HEXAGON HEAD
943 1PTF0403116 1PTF0403116 1PTF0403116 SCREW,TAP TITE D4.0 L16.
- 19 -
EXPLODED VIEW PARTS LIST
LOCA. NO
14” 20” 21”
PART NO
DESCRIPTIONS
The components identified by mark are
critical for safety.
Replace only with part number specified.
