- 21 -
112 2426GDA80CC CPT SET,A51QAE320X 24M7KR
120 120-C77N SPEAKER,FULLRANGE,C122S01K1450 ESTEC MID-RANGE 8OHM 15/25W 84.5DB OTHERS
121 6400VG0002A SPEAKER,TWEETER,T0520101(C76G) BUKDOO 8 OHM 10/20W 88DB D52X74X17.5MM
122 4810V00498A BRACKET,SPK(SHAHAB EXPORT) . .
150 150-D02X COIL,DEGAUSSING,CU 21” 60TURN 12 OHM D02N (NYLON)
170 170-A01D LEAD SET,CPT EARTH(19”)
174 174-009E POWER CORD,POWER(W/HOLD,HOUSING,L=200,4.0
300 3091V00497B CABINET ASSEMBLY,RF-21CB90VQ(PPL,SHAHAB) NON MC019A
310 5020V00801A BUTTON,CONTROL RT-21CB90 ABS, HF-380 6KEY EXPORT SHAHAB”
320 320-062E SPRING,KNOB
330 5020V00800A BUTTON,POWER RT-21CB90 ABS, HF-380 1KEY EXPORT SHAHAB
340 5020V00802A BUTTON,TURBO RT-20CB90 ABS, HF-380 2KEY EXPORT SHAHAB
350 3750V00046B RACK,BASE ASSY RF-21CB90VQ(PPL) .
354 4980V00035A SUPPORTER,BASE EVA NONE
400 3809V00345B BACK COVER ASSEMBLY,RF-21CB90VQ(PPL) 1PHONE .
520 6871VMMP38Q PWB(PCB) ASSEMBLY,MAIN MC019A RF-21CB90VQ.KMLLKS2(SHAHAB PPL)
540 6871VSM360R PWB(PCB) ASSEMBLY,MAIN SUB TURBO(019A/B)PIC/SOUND (W/O GAME)F-CKD ETC.
700 0IGL120104A IC,LG SEMICONDUCTOR,CDS SENSOR MODULE(P1201-04)
913 332-057B SCREW,DRAWING ASSY,HEXAGON HEAD
943 1PTF0403116 SCREW,TAP TITE(P)[TRUSS HEAD]
EXPLODED VIEW PARTS LIST
LOCA. NO
PART NO
DESCRIPTIONS
The components identified by mark are
critical for safety.
Replace only with part number specified.
To Next Page
