LG S77S - Sound Bar Quick Guide; Installing and Using the Product

2
Sound Bar Quick Guide
Installing and using the Product
a Connect the sound bar to your TV via an optical cable or an HDMI
cable.
HDMI OUT
HDMI IN
(ARC)
HDMI IN
OPTICAL
OUT
OPTICAL
IN
5 V 0 500 mA
HDMI IN
TM
HDMI d TV
(eARC / ARC)
TM
a
b
D
a
A
B
C
b
E
1
2
3
A Sound bar
B Remote Control Receiver
C Status LED (ABC)
D Wireless Subwoofer - Install it close to the sound bar.
E External Device - (Blu-ray player, game console, etc.)
Soundbar Quick Guide
