LG S77S - External Device Connection via HDMI B

33
Connecting an external device via HDMI B
a Connect an external device such as a Set-top box, DVD or Blu-ray player. Following the picture below, connect
the HDMI OUT terminal of the device to the HDMI IN terminal on the TV.
b Using the HDMI cable, connect the HDMI™ d TV (eARC / ARC) terminal on the back of the product to the
HDMI IN (ARC) terminal on the TV.
OPTICAL
IN
5 V 0 500 mA
HDMI IN
TM
HDMI d TV
(eARC / ARC)
TM
c Press the Function button repeatedly until LED1 lights up white.
1
2
3
d When the external device is properly connected to the product, you can listen to the sound of the device.
Note
• There may be no sound depending on the specifications of the connected TV. It is recommended to connect the
external device directly to the product. ([ See “Connecting an external device via HDMI A” on page 31.)
