1-7
SPECIFICATIONS
• GENERAL
Power consumption 22 W
Networked standby : 0.5 W (If all network ports are activated.)
AC adapter Model : DA-38A25
Manufacturer : Asian Power Devices Inc.
Input : 100 - 240 V ~ 50 - 60 Hz 1.2 A
Output : 25 V 1.52 A
Dimensions (W x H x D) Approx. 945 mm x 53 mm x 85 mm, Without foot
Net Weight Approx. 2.6 kg
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Bus Power Supply 5 V 500 mA
Available Digital Input Audio
Sampling Frequency 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Available Digital Input Audio format Dolby Digital, DTS Digital Surround, PCM
• INPUT/OUTPUT
OPTICAL IN (Digital audio in) 3 V (p-p), Optical jack x 1
PORTABLE IN (Portable in) 0.5 Vrms (3.5 mm stereo jack) x 1
HDMI IN 19 Pin (Type A, HDMI™ connector) x 1
HDMI OUT 19 Pin (Type A, HDMI™ connector) x 1
• AMPLIFIER (RMS OUTPUT)
Total 320 W
Front 60 W x 2 (4 Ω at 1 khz, THD 10%)
Subwoofer 200 W (3 Ω at 80 Hz, THD 10%)
• WIRELESS SUBWOOFER
Power requirements Refer to the main label on the subwoofer.
Power consumption Refer to the main label on the subwoofer.
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 200 W
Max. Input Power 400 W
Dimensions (W x H x D) Approx. 171 mm x 320 mm x 252 mm
Net Weight Approx. 4.2 kg
• Designs and specifications are subject to change without prior notice.
