LG SL4Y - Rear speakers connection

2-4
Copyright © 2019 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
Figure 1-6
Figure 1-5
HOW TO DISASSEMBLE THE MAIN SET
6) Remove the 4 screws and Disconnect FFC cables (BT, Wireless).
5) Remove the L/R Deco Assembly.


BT
Wireless
