LG SPH5B-W Service Manual

3-243-23
Top
Side
FFC
Harness
Bottom
Side
T
op
S
i
d
e
FF
C
H
a
a
r
n
e
s
s
B
o
tt
o
m
S
i
d
e
B to B
KEY
FRONT
USB
PTB
OPT
ADAPTER
HDMI
4P, 2.0mm
ST, Non Lock , SMD
(EAG63270202)
5P, 2.0mm
ST, Non Lock , SMD
(EAG63270203)
MAIN
LCD Module
2P, 1.25mm
ST, Non Lock , SMD
(EAG60989201)
2P, 1.25mm
AG, Non Lock SMD
(6630V901352)
12P, 2mm
ST, SOCKET, SMD
(EAG63717501)
HDMI
26P, 0.5mm
ST, Non_Lock, SMD
(6630X60142K)
10P, 1.0mm
AG, Lock, SMD
(EAG62611102)
Wireless
A
G
62611102
26
26
Bluetooth
12P, 2mm
AG, MALE, SMD
(EAG64811001)
WIRING DIAGRAM

LG SPH5B-W Specifications

General

Brand	LG
Model	SPH5B-W
Category	Speaker System
Language	English
