LG StudioWorks 585E - Exploded View

EXPLODED VIEW PARTS LIST
- 22 -
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14-1
14-2
15
A
B
a
b
c
d
Part No.
3091TKB038B
6318L15002B
3809TKB013D
3043TKK039C
339-002D
6140TC3006B
6174T13012A
or 6174Z-1035H
6620TKB002D
or 6620TKB002A
or 6620TKB002B
6871TST294B
4810TKK141A
4810TKK142A
4950TKS156B
332-102F
3550TKK059A
3550TKK059B
3550TKK060A
3313T15085B
6871TMT397B
4001TKK004E
332-112F
332-113F
332-095B
Description
CABINET ASSEMBLY, CR575E IOMG B033 LUPOY 85964 (ASSY LOCAL)
CDT(CIRC), M36LBL803X49LAA LG-PHILIPS 64KHZ 29.1MM FST MPR
BACK COVER ASSY, CB575 3808TKB017A CKD.TCO
TILT SWIVEL ASSEMBLY, KCB575 B028A,T031A LOCAL
SCREW ASSY, PHP+5*30BP(FZMY)+GW18
COIL,DEGAUSSING, 75D-437 KWANGSUNG CB563G NT
FBT (FLY BACK TRANSFORMER), C93 BSC23-1435 HITACHI 15"
FBT (FLY BACK TRANSFORMER), FMMTC81-M1035H LG-PHILIPS 15"
SOCKET(CIRC), POWER, CDJ-3C DUOLING AC UNIVERSAL 3PIN BLACK
SOCKET(CIRC), POWER, BAE EUN AC UNIVERSAL 3PIN BLACK
SOCKET(CIRC), POWER, SA-4S HUA JIE AC UNIVERSAL 3PIN BLACK
PWB(PCB) ASSEMBLY, SUB, CR575G CONTROL TOTAL IOMG CA-117
BRACKET, CB575C GUIDE ABS (R)
BRACKET, CB575C GUIDE ABS (L)
METAL SHIELD BOTTOM CB575C "A" CKD
SCREW, PTP+4*20BP(MSWR/FZMY)
COVER, CB575 SCREW (RIGHT)
COVER, CB575 SCREW (LEFT)
COVER, CB575 PIECE REAR
MAIN TOTAL ASSEMBLY, CR575H BRAND CA-126
PWB(PCB) ASSEMBLY, MAIN, CR575H KLIOEI BRAND CA-126 TOTAL
SCREW ASSEMBLY, TAPTITE P TYPE D3.0 L10.0 MSWR/FZMY SW3+RW10
SCREW, DRAWING, D3.5 L10.0 MSWR/FZMY +SW3.5+RW3.5
SCREW, PVP+3*12(MSWR/FZMY)
SCREW, DRAWING, PZP+3*10(MSWR/FZMY)
