H + 68.677 14.561 10.836 3.725 1.016 0.508 2.201
V + 85.00 11.764 11.182 0.582 0.044 0.014 0.524
H – 37.50 26.67 20.32 6.35 2.03 0.51 3.81
V – 74.99 13.335 12.802 0.533 0.080 0.026 0.427
H + 46.88 21.33 16.16 5.17 1.62 0.32 3.23
V + 75.01 13.331 12.798 0.533 0.064 0.021 0.448
H + 53.68 18.63 14.22 4.41 1.14 0.57 2.70
V + 85.07 11.755 11.178 0.577 0.056 0.018 0.503
Mode
H/V
Sort
1
2
3
4
640x480
75Hz
800x600
60Hz
1024x768
85Hz
800x600
75Hz
<< Dot Clock (MHz), Horizontal Frequency (kHz), Vertical Frequency (Hz), Horizontal etc... (µs), Vertical etc... (ms) >>
Sync
Polarity
Frequency
Total Period
(E)
Video Active
Time (A)
Sync Duration
(D)
Blanking Time
(B)
Front Porch
(C)
Back Porch
(F)
Resolution
