18. Loosen 8 screws and remove the cap covers on both
sides.
19. Loosen 4 screws on the hinge side, remove the
hinge bracket, and detach the pants press.
20. Loosen 2 screws on the locker side and remove the
locker.
21. Remove 8 cap covers located on both sides of the
pants press and loosen the screws to detach the lock-
er holder and hinge.
22. Loosen 2 screws and detach the locker hook. Move
the locker hook and hinge on the left to the right and
vice versa to assemble them in the reverse order of
disassembly.
23. Attach the pants press on the door, move the hinge
bracket and locker on the left to the right and vice
versa to assemble the door in the reverse order of dis-
assembly.
Hinge bracket
Locker h o o k
Locker
Locker area
Hinge area
