109
24. Loosen two top hinge xing screws and two
bottom hinge xing screws completely to
protrude them approx. 15 mm on the op-
posite side.
25. Loosen the screws and attach the cap cover
on the opposite side.
26. Tighten 3 screws at the top of the 'L' top
bracket and tighten 4 screws at the bottom.
27. Insert the hinge to the loosened screws and
pull it to the right to x it.
Cap cover
Top bracket (L)
