63
Normal
Delicates
Time Dry
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
120 (P120/
M1200~1800)
150 (P120/
M1600)
30~150 (P120/
M1200~1800)
Moving hanger
operation
- - -
Operation: 30 seconds after the cycle started
Component used
Water supply/
drain pump
Steam heater
Main fan
Motor
Comp
LEV
Steam heater
Water drain pump
Main fan motor
STEAM HEATER
MAIN FAN MOTOR
MAIN FAN
MOTOR
M/H MOTOR
MAIN FAN MOTOR
M/H MOTOR
Water supply/drain pump
Comp
LEV
Main fan motor
M/H motor
Operation
Heat to 95 ℃ after
supplying water to
full level.
Increase internal
temperature to
maximize the steam
effect.
Operate the steam heater
for the set duration to inject
steam.
- Styling course
conducts M/H
operation
to maximize
the efficiency
of wrinkle
removal.
- Sterilization
course turns
off all devices
and stands by
to maximize
the sterilization
effect.
Operate the main
fan and M/VIH
Operate the main fan and
comp for the set duration.
Other
Water supply
error occurs when
the full water level
is not detected
within the
maximum duration
(5 minutes).
When Duct In is
maintained for
10 seconds at a
temperature above
40 ℃, the next
cycle starts after 10
minutes.
- When low water level is
detected during heating,
the next cycle starts.
- LEV is at 200 when the
cycle starts.
- Comp operates 1 minute
after the cycle starts.
※P:PulleyRPM,M:MotorRPM
※DataViewPulleyRPM=PulleyRPM×3/5
11-2. Cycle Characteristics - Drying
