67
12-2. When Feed Water LED is blinking
Is the water supply tank full of water?
Is the water supply tank properly connected to the product?
※
Check if it is properly inserted.
Is the power consumption of water supply pump 10 or above?
※
Check it in the Test mode.
10 or below: Remove the housing.
10 or above: Assembled properly.
Is the condition of the water supply hose good? (no bending/
folding/tearing)
Is the reed switch behind the rear cover in normal position?
Is the reed switch connector (WH2) connected?
Fill the water in water supply tank and operate.
Press the water supply tank to check whether it is
properly inserted.
Detach the front part and connect the connector.
Replace the hose.
Attach the reed switch properly.
Connect the connector.
Is the check valve between water supply valve and generator in
good condition? (no clogging)
Clean or replace the check valve.
NO
NO
NO
NO
NO
NO
YES
YES
YES
YES
YES
YES
NO
YES
To Next Page
