LG Styler S3RERB - Page 68

68
Is the water supply pump connector (WH2) properly assembled?
Is there check valve on the AG?
 Product number: G
Are the AG water level sensor connectors (WH2, WH1)
connected?
Are the main PCB connectors (WH8, YL4, BL12) properly
assembled?
Replace the main PCB.
Connect the connector.
Remove the check valve.
Connect the connector.
Connect the connector.
NO
NO
NO
NO
YES
YES
YES
YES
