21
EN
Control Panel
4 3
2
1
5
POWER Button
• Press the POWER button to turn the
washing machine on.
• The power goes off automatically about 10
seconds after the wash is finished.
START/PAUSE Button
• Press the START/PAUSE button to start
the wash cycle or pause the wash cycle.
• If a temporary stop of the wash cycle is
needed, press the START/PAUSE button.
1
Program Button
• Programmes are available according to
laundry type.
• Lamp will light up to indicate the selected
programme.
Option Button
• Press buttons to select the desired options.
Display
• The display shows the settings, estimated
time remaining, options, and status
messages. When the product is turned
on, the default settings in the display will
illuminate.
• The process lamp will remain prior to it
beginning. The process lamp will blink
during that process, and the lamp will then
turn off when that process has completed.
3
To Next Page
